TS90S

Specifications

• Temperature Range: 0°C to +90°C (32°F to 194°F)
• Accuracy: ±3%
• Electric Rating: 20A at 250V AC
• Switch Type: SPST or SPDT (Single Pole Single Throw or Double Throw)
• Reset Type: Automatic reset
• Bulb & Capillary Tube Material: 300 Series Stainless Steel
• Standard Capillary Tube Length: 1,000mm (approximately 39 inches)
• Bulb Dimensions: Ø5.8 mm x 120 mm
• Mounting: M4 fixed bracket
